Plug & Play 800W Solar System with 2 × 460W Panels + Microinverter

Plug & Play and ready to generate solar energy at home. This compact 800W Plug & Play Solar System combines two JA Solar DeepBlue 4.0 Pro 460W N-Type monofacial double-glass solar panels, a Hoymiles HMS-800-2WB HiFlow Pro microinverter and a 5m Type-G UK Plug & Play AC cable.

With a combined rated solar-panel capacity of 920Wp, the system provides additional DC capacity to support useful generation during variable UK weather conditions. The Hoymiles microinverter converts the DC electricity produced by the panels into usable AC electricity, with a maximum rated AC output of 800VA.

The two JA Solar panels use modern N-Type monofacial double-glass technology, combining high-efficiency solar-cell technology with durable double-glass construction. This provides a robust and reliable panel design suitable for long-term residential and commercial solar installations.

Each panel measures 1762 × 1134 × 30mm. This package does not include a mounting system, allowing you to select a suitable mounting solution separately according to where and how the panels will be installed.

The Hoymiles HMS-800-2WB has two independent MPPT channels, allowing each solar panel to be managed individually. This helps optimise generation when the panels experience slightly different sunlight levels, temperatures or operating conditions.

Built-in 2.4GHz Wi-Fi and Bluetooth make commissioning and monitoring straightforward. The system works with the S-Miles Home App, allowing you to view solar generation without purchasing an additional DTU.

Complete Plug & Play Solar Package

• 2 × JA Solar DeepBlue 4.0 Pro 460W N-Type monofacial double-glass solar panels
• 1 × Hoymiles HMS-800-2WB HiFlow Pro 800W microinverter
• 1 × 5m Type-G UK Plug & Play AC cable
• 920Wp combined rated DC panel capacity
• 800VA maximum rated AC output
• Two independent MPPT channels for individual panel optimisation
• Built-in Wi-Fi and Bluetooth
• Monitoring through the S-Miles Home App
• No additional DTU required
• ENA compliant configuration – WORLD/21446/V1/A5
• Mounting system not included

Flexible Installation

This package brings together the main electrical components required for a compact Plug & Play solar system. There is no need to select the panels and microinverter separately, helping make the purchasing process clearer for customers who are new to solar energy.

Because no mounting system is included, you can choose a mounting solution appropriate for your intended installation location. This gives you greater flexibility if you already have suitable mounting equipment or require a specific solution for a garden, patio, flat roof, wall or other appropriate location.

The panels should be positioned where they can receive good sunlight with minimal shading. The appropriate orientation and mounting arrangement will depend on the property, available space and household electricity-consumption pattern.

JA Solar 460W N-Type Monofacial Panels

• 460W rated power per panel
• 920Wp combined rated panel capacity
• Modern N-Type solar-cell technology
• Monofacial module design
• Durable double-glass construction
• Panel dimensions: 1762 × 1134 × 30mm
• Suitable for use with the included Hoymiles microinverter

Hoymiles HMS-800-2WB Microinverter

• 800VA rated AC output power
• Designed for connection to two compatible solar panels
• Two independent MPPT channels
• One DC input per MPPT
• Built-in 2.4GHz Wi-Fi
• Built-in Bluetooth for local commissioning
• Monitoring through the S-Miles Home App
• No additional DTU required
• IP67 outdoor enclosure rating
• Fanless natural-convection cooling
• Supplied with a 5m Type-G UK Plug & Play AC cable

Choose Your Own Mounting System

No solar-panel mounting system is included with this package. A suitable mounting solution must therefore be selected separately according to the intended installation location and site conditions.

This makes the package particularly useful if you already have a suitable mounting system or want to choose from different installation options rather than being restricted to one type of mount.

Any mounting system used should be suitable for the dimensions and weight of the supplied solar panels and installed in accordance with the mounting manufacturer's instructions and applicable installation requirements.

Important Installation Information

Before ordering, measure the intended cable route between the microinverter and the connection point. The package includes a 5m UK AC cable; alternative cable lengths may be available separately where a longer route is required.

The combined solar-panel rating of 920Wp is higher than the microinverter’s maximum 800VA AC output. This intentional DC-to-AC sizing can support improved generation during lower-light conditions. When available panel power exceeds the inverter’s maximum output, the microinverter will limit its AC output to its permitted maximum.

Please note: Actual solar generation depends on location, orientation, shading, season, weather, panel temperature and installation conditions.
